Training single and multimodal AstroPT models

This guide describes how to train AstroPT-style Large Observation Models (LOMs) using the provided training scripts.

Overview

We provide two example training scripts in scripts/:

train.py - For training on single-modality data (here galaxy imagery)
train_multimodal.py - For training on multiple modalities (here both galaxy imagery and spectral data)

Of course they can be modified for any modality after altering the tokeniser and position embedding code. Both scripts support single-GPU and distributed multi-GPU training with Distributed Data Parallel (DDP).

Command-line usage

Single GPU

# For single-modality training
python train.py

# For multi-modality training
python train_multimodal.py

Distributed Data Parallel (4 GPUs on 1 node)

# For single-modality training
torchrun --standalone --nproc_per_node=4 train.py

# For multi-modality training
torchrun --standalone --nproc_per_node=4 train_multimodal.py

Distributed Data Parallel (8 GPUs across 2 nodes)

On the first (master) node:

# For either training script
torchrun --nproc_per_node=8 --nnodes=2 --node_rank=0 --master_addr=123.456.123.456 --master_port=1234 train.py  # or train_multimodal.py

On the worker node:

# For either training script
torchrun --nproc_per_node=8 --nnodes=2 --node_rank=1 --master_addr=123.456.123.456 --master_port=1234 train.py  # or train_multimodal.py

Key differences between scripts

While train.py and train_multimodal.py share most of their code base, there are several important differences:

Modality configuration

train.py configures a single modality for galaxy imagery:

modalities = [
    ModalityConfig(
        name="images",
        input_size=16 * 16 * n_chan,
        patch_size=16,
        loss_weight=1.0,
        embed_pos=True,
        pos_input_size=1,
    ),
]

train_multimodal.py configures multiple modalities:

modalities = [
    ModalityConfig(
        name="images",
        input_size=16 * 16 * n_chan,
        patch_size=16,
        loss_weight=1.0,
        embed_pos=True,
        pos_input_size=1,
    ),
    ModalityConfig(
        name="spectra",
        input_size=256,
        patch_size=256,
        pos_input_size=256,
        loss_weight=0.5,
        embed_pos=False,
    ),
]

Dataset handling

train.py can stream Hugging Face datasets (here we use Smith42/galaxies):

# When use_hf=True
tds_hf = load_dataset("Smith42/galaxies", split="train", streaming=True)

train_multimodal.py uses local file paths for both modalities:

tds = GalaxyImageDataset(
    paths={"images": "./hsc_matched.txt", "spectra": "./spectra_matched.txt"},
    spiral=spiral,
    transform=transforms,
    modality_registry=modality_registry,
)

where hsc_matched.txt and spectra_matched.txt are crossmatched text files of the same length with one line per FITS or JPG image/spectra.

Configuration options

Both scripts support numerous configuration parameters that can be set via command line or configuration files:

Model architecture

n_layer: Number of transformer layers
n_head: Number of attention heads
n_embd: Embedding dimension
n_chan: Number of image channels
block_size: Maximum sequence length
dropout: Dropout rate (0.0 recommended for pretraining)
bias: Whether to use bias in LayerNorm and Linear layers
attn_type: Attention type (“causal” is standard)

Data parameters

gradient_accumulation_steps: Number of steps to accumulate gradients
batch_size: Batch size per GPU
spiral: Process galaxy patches in spiral order (as described in our paper)
image_size: Size of input images
use_hf: Use Hugging Face dataset version (train.py only)
stream_hf_dataset: Stream the galaxies from Hugging Face (train.py only)

Optimiser settings

learning_rate: Maximum learning rate
weight_decay: Weight decay value
beta1: Adam beta1
beta2: Adam beta2
grad_clip: Gradient clipping value
decay_lr: Whether to decay learning rate
warmup_iters: Warmup iterations
lr_decay_iters: Total iterations for LR decay
min_lr: Minimum learning rate (learning_rate/10)

Training loop settings

max_iters: Total number of training iterations
eval_interval: Interval for evaluation
log_interval: Interval for logging
eval_iters: Number of batches for evaluation
checkpoint_interval: Interval for saving checkpoints
eval_only: Only perform evaluation, no training
always_save_checkpoint: Always save checkpoints regardless of loss
init_from: Initialize from scratch or resume training

System settings

device: Device to use (default: “cuda”)
dtype: Data type to use (default: “bfloat16”)
compile: Use PyTorch 2.0 to compile the model
backend: DDP backend (default: “nccl”)
out_dir: Output directory for logs and checkpoints
log_via_wandb: Use WandB for logging
log_emissions: Use CodeCarbon to track emissions

Configuration files

Instead of specifying all parameters via command line, you can create a configuration file:

# config/astropt.py
out_dir = "logs/astropt"
batch_size = 32
n_layer = 24
n_head = 16
n_embd = 1024

And then pass it to the script:

python train.py config/astropt.py  # or train_multimodal.py

You can also override specific parameters from the config file:

python train.py config/astropt.py --batch_size=64

We have example config files in config.

Creating custom dataloaders

The AstroPT training pipeline uses the GalaxyImageDataset class from local_datasets.py to handle data loading and preprocessing. You can create your own custom dataloader for different modalities by extending this class or creating a similar class that follows the same interface.

Here’s a guide to creating a custom dataloader for AstroPT:

Basic structure

Your dataloader should inherit from torch.utils.data.Dataset and implement the following methods:
- __init__: Initialize dataset with paths, transforms, and modality registry
- __len__: Return the dataset length
- __getitem__: Return a dictionary of data for each index
- process_modes: Process data into X and Y tensors for the model

Example skeleton

class CustomDataset(Dataset):
    def __init__(self, paths, transform=None, modality_registry=None):
        """
        Args:
            paths (dict): Dictionary of paths for each modality
            transform (dict, optional): Dictionary of transforms for each modality
            modality_registry: ModalityRegistry object containing modality configurations
        """
        self.paths = paths
        self.transform = transform
        self.modality_registry = modality_registry

    def __len__(self):
        """Return the total number of samples in the dataset"""
        return len(self.paths[list(self.paths.keys())[0]])

    def __getitem__(self, idx):
        """Get a single sample from the dataset"""
        # Process each modality and return a dictionary
        result = {}

        # Example for image modality
        if "images" in self.paths:
            # Load and process image data
            image_data = self.load_image(self.paths["images"][idx])
            processed_image = self.process_image(image_data)
            result["images"] = processed_image
            result["images_positions"] = torch.arange(0, len(processed_image), dtype=torch.long)

        # Example for another modality
        if "spectra" in self.paths:
            # Load and process spectral data
            spectral_data = self.load_spectrum(self.paths["spectra"][idx])
            processed_spectrum, wavelengths = self.process_spectrum(spectral_data)
            result["spectra"] = processed_spectrum
            result["spectra_positions"] = wavelengths

        result["idx"] = idx
        return result

    def load_image(self, path):
        """Load image data from path"""
        # Implement loading logic for your image format
        pass

    def process_image(self, image_data):
        """Process loaded image data into model-ready format"""
        # Implement processing logic (patching, standardization, etc.)
        pass

    def load_spectrum(self, path):
        """Load spectral data from path"""
        # Implement loading logic for your spectral format
        pass

    def process_spectrum(self, spectral_data):
        """Process loaded spectral data into model-ready format"""
        # Implement processing logic
        pass

    @staticmethod
    def process_modes(x, modality_registry, device, shuf=False):
        """
        Process data dictionary into X and Y tensors for model input/output
        Args:
            x (dict): Data dictionary from __getitem__
            modality_registry: ModalityRegistry object
            device: torch device to move tensors to
            shuf (bool): Whether to shuffle modality order
        Returns:
            dict: Dictionary containing 'X' and 'Y' keys with model-ready tensors
        """
        modes = modality_registry.generate_sequence(shuf=shuf)

        # Move all tensors to device
        x_on_device = {
            k: v.to(device) if isinstance(v, torch.Tensor) else v for k, v in x.items()
        }

        X = {}
        Y = {}

        # Process each modality
        for ii, mode in enumerate(modes):
            X[mode] = x_on_device[mode]
            X[f"{mode}_positions"] = x_on_device[f"{mode}_positions"]
            Y[mode] = x_on_device[mode]

            # Handle autoregressive prediction (shift by one token)
            if ii == 0:
                Y[mode] = Y[mode][:, 1:]
            if len(modes) == 1:
                X[mode] = X[mode][:, :-1]
                X[f"{mode}_positions"] = X[f"{mode}_positions"][:, :-1]

        return {"X": X, "Y": Y}

Example: custom spectra dataset

class StellarSpectraDataset(Dataset):
    def __init__(self, paths, transform=None, modality_registry=None):
        self.paths = paths
        self.transform = transform
        self.modality_registry = modality_registry

        # Read file paths
        if "spectra" in paths and paths["spectra"] is not None:
            self.spectra_paths = np.genfromtxt(paths["spectra"], delimiter=",", dtype=str)
        else:
            self.spectra_paths = None

        # Set length to the first non-None dataset
        self.dataset_len = len(self.spectra_paths) if self.spectra_paths is not None else 0

    def __len__(self):
        return self.dataset_len

    def process_spectrum(self, raw_spectrum, wavelength):
        patch_size = self.modality_registry.get_config("spectra").patch_size

        # Apply padding to the spectrum to make it divisible by patch_size
        w = raw_spectrum.shape[0]
        pad_w = (patch_size - w % patch_size) % patch_size
        padded_spectrum = F.pad(raw_spectrum, (0, pad_w))
        padded_wl = F.pad(wavelength, (0, pad_w))

        # Rearrange into patches
        patch_spectrum = einops.rearrange(
            padded_spectrum,
            "(w p) -> (w) (p)",
            p=patch_size,
        )

        patch_wl = einops.rearrange(
            padded_wl,
            "(w p) -> (w) (p)",
            p=patch_size,
        )

        # Apply transforms if specified
        if "spectra" in self.transform:
            patch_spectrum = self.transform["spectra"](patch_spectrum)

        return patch_spectrum, patch_wl

    def __getitem__(self, idx):
        try:
            # Load spectral data from FITS file
            with fits.open(self.spectra_paths[idx]) as hdul:
                raw_spectrum = hdul[1].data["Flux"].astype(np.float32)
                wavelength = hdul[1].data["Wave"].astype(np.float32)

            # Convert to tensor and normalize
            raw_spectrum = torch.tensor(raw_spectrum).to(torch.bfloat16)
            wavelength = (torch.tensor(wavelength).to(torch.bfloat16) - 3000) / (10000 - 3000)

            # Process the spectrum
            patch_spectrum, patch_wl = self.process_spectrum(raw_spectrum, wavelength)

            # Check for NaN values
            if torch.isnan(patch_spectrum).any() or torch.isnan(patch_wl).any():
                raise ValueError("Found NaNs in spectra, skipping file")

            return {
                "spectra": patch_spectrum,
                "spectra_positions": patch_wl,
                "idx": idx,
            }

        except Exception as err:
            print(f"Error processing file {self.spectra_paths[idx]}: {err}")
            raise

    @staticmethod
    def process_modes(x, modality_registry, device, shuf=False):
        modes = modality_registry.generate_sequence(shuf=shuf)

        x_on_device = {
            k: v.to(device) if isinstance(v, torch.Tensor) else v for k, v in x.items()
        }

        X = {}
        Y = {}
        for ii, mode in enumerate(modes):
            X[mode] = x_on_device[mode]
            X[f"{mode}_positions"] = x_on_device[f"{mode}_positions"]
            Y[mode] = x_on_device[mode]
            if ii == 0:
                Y[mode] = Y[mode][:, 1:]
            if len(modes) == 1:
                X[mode] = X[mode][:, :-1]
                X[f"{mode}_positions"] = X[f"{mode}_positions"][:, :-1]

        return {"X": X, "Y": Y}

Integration with training script

To use your custom dataloader in the training script:

Import your custom dataset class
Replace the GalaxyImageDataset instantiation with your custom dataset
Use the same dataloader configuration as in the original script

from custom_dataloader import CustomDataset

# ...

# Initialize custom dataset
tds = CustomDataset(
    paths={"modality1": "path1.txt", "modality2": "path2.txt"},
    transform=transforms,
    modality_registry=modality_registry,
)

# Create DataLoader with the custom dataset
tdl = iter(
    DataLoader(
        tds,
        batch_size=batch_size,
        num_workers=num_workers,
        pin_memory=True,
    )
)

Output and monitoring

During training, both scripts provide:

Loss values for training and validation sets
Visual comparisons of original data and model predictions
Checkpoint saving based on validation performance
Optional WandB integration for experiment tracking
MFU (Model FLOP Utilization) estimates
Optional carbon emissions tracking

The training progress, model visualizations, and metrics are saved to the specified output directory.
